LISI Auto in Heidelberg production base upgrade 494

MAIN
Team : Constantin Stoilov, Raya Pravdomileva
PROJECT #494
LISI 512x512 2
Customer : LISI Automotive Mechano GmbH
Period : 2018
Contractor : IPS Germany GmbH
Discipline : Civil & Structural
Tags : machinery • concrete • steel
LOCATION
Coordinates :
Google Earth [LINK] & Google Earth [PROJECT]
KML file : Download KML file
DOCUMENTS
PDF : view file (O1280-STR-17-02-A1_cssproject_eu.pdf)
PDF : view file (O1280-STR-14-04-A1_cssproject_eu.pdf)
PDF : view file (O1280-STR-10-01-A2_cssproject_eu.pdf)
PDF : view file (O1280-STR-05-02-A0_cssproject_eu.pdf)
PDF : view file (O1280-STR-03-04-A1_cssproject_eu.pdf)



PROJECT DYNAMIC MAP
DESCRIPTION

A design mission from: conception to details. These separate structures were included: [1] Hardening Shop – precast concrete structure [2] Quality Control Room – masonry [3] Main Storage – steel structure [4] A canopy between [1] and [3] – steel structure [5] Logistic canopy – steel structure [6] Furnaces foundations in [1] – reinforced concrete structure It was a challenge: to design in accordance with German annexes of the Eurocodes and the designed to be approved by German control engineer.
