2 year design project for systems of new & reconstructed pipe& cable racks with ADM Razgrad factory. Complexity came from the great number of technological lines and many existing obstacles to consider. Capacitive design principles implemented in seismic checks of the new & reconstructed structures. Prepared shop drawings of entire 466t steel structures.
Chocolate Storage Tower 559
At the plant in Svoge a need for extra chocolate mass storage appeared. The chocolate is stored in specific stainless steel heated vessels [tanks 26t each one full]. The only possible location [close to production lines] was already occupied with tanks for raw products. The structural solution found is: to build a tank farm at
Reconstruction of mosaic elements workshop into auto repair shop, Druzba q. 161
Former out-of-operation mosaic elements workshop was purposed to become auto repair garage. By these means were designed: internal floors, foundation for equipment, roof sky lights were replaced, separation walls, truck maintenance channels, etc.
Chocolate Storage Tower 473
At a tiny space, at the back yard of Chocolate Factory of Mondeleez we designed a custom fitted steel structure. This allowed situation of 4 chocolate storage tanks, at two levels. In reverse to existing chocolate storage tower near-by, the new one as wide in plan and in elevation for normal maintenance of the tanks.
Alcohol Storage 576
Small, never-the-less a complex project, for ethyl alcohol storage upgrade to contemporary standards. Designed were: two steps cooling system combined with ventilation, specific gas[argon] fire fighting system, new alcohol storage vessel, electrical installation.
Lekos Extension 462
Chocolate factory in Svoge is limited for its extension from south by mountain hill and from north, east and west by Iskretska river bed. This extension of production facilities „Lekos“ we manage to realize by wise use of the slopped terrain: we designed technologically connected a two story building attached to the existing one level
Imotion workshop & administration 155
Imotion OOD [later joint to TRELLEBORG https://www.trelleborg.com/en] workshop & administration. Full set of discipline design of two buildings. Administrative – casted at site reinforced concrete structure with two floors and basement. Production building – precast concrete columns, casted foundation and intermediate floor, steel roof structure.
Store & office, Ravno pole 297
Logistic base with office within a 5000sq.m. plot. Steel structures over 2 spans of 12m. Height of 9.7m
Elevator Tower 484
This project enable general technological flow in chocolate factory in Svoge to be reversed. Second level of production building was made accessible for raw products supply by attaching elevator tower next to the building. Tower hosts elevator and tilting platform that allows attached trucks to be unloaded by forklift. Leaded my technological design, steel structure
New Chimney, Kraft Foods, Svoge 399
Boilers and steam generators in Chocolate Factory were upgraded by previous project. These start working with CNG. Extra water created in burning CNG penetrates within concrete walls of used 63m high reinforced concrete chimney. This, together with the freeing temperatures in winters lead to critical status of the chimney. Chimney with such height was not
